emz smart Sol - Commissioning Mode: Post Heating Requirements; Post-Heating Configuration

Page 58
1.3.10 Post Heatin...
04. 07. 2015 09:29
Activation
Boiler type
Hysteresis
Min. temp.
Solid fuel boiler
10.0K
40.0°C
1.3.10 Post Heatin...
04. 07. 2015 09:29
Max. temp.
Sensor boiler
Time block 1
Time block 2
Time block 3
55.0°C
TS4
1.3.10 Time block 1
04. 07. 2015 09:29
Activation
Ref. temp.
Starting time
End time
45.0°C
00:00
23:59
›Ref. temp.‹ is used to dene the set
temperature at the top tank sensor.
If the temperature falls below ›Ref. temp.‹
by ›Hysteresis‹, the control activates the
reheating cycle via the heating boiler until
›Ref. temp.‹ is reached.
COMMISSIONING MODE
Use ›Boiler sensor‹ to assign the temperature
sensor which supplies the temperature value
of the boiler.
Up to six time blocks can
be activated for reheating.
Here, reheating can be activated.
The boiler is dened as
›Solid-fuel boiler‹ or ›Gas/oil‹.
In case of solid-fuel boilers reheating is made
via the charge pump of the drinking water
tank and is only activated if the temperature
of the tank is within the values ›Min. temp.‹
and ›Max. temp.‹.
