emz smart Sol - Malfunction Handling: Sensor Breakage Example; Sensor Breakage Error M02

Page 79
1.10 Service Wizard
04. 07. 2015 10:33
M02:
Breakage of
sensor on TS1!
Menu Next
1.10 Service Wizard
04. 07. 2015 10:33
M02:
Breakage of
sensor on TS1!
Menu Next
1.10 Service Wizard
04. 07. 2015 10:33
Possible reasons:
Cable/connection
Sensor
Exit
MALFUNCTION
The Service Wizard helps detect
possible causes of malfunctions.
Acknowledge by pressing ›Next‹.
For this malfunction,
the following causes are assumed:
›Cable/connection‹ or ›Sensor‹ -
select the rst menu item and
conrm by pressing ›OK‹.
›1.10 Service Wizard‹ appears.
The malfunction appears in plan text - here:
›M02: Breakage of sensor on TS1!‹.
If an analysis/repair is not
required at present, press ›Menu‹
to return to the main menu.
Danger!
Mortal danger due to electrocution!
For troubleshooting on the plant, disconnect all poles of the power
supply reliably and protect it them against being switched on again!
