1.10 Service Wizard
04. 07. 2015 10:33
Please check the
connection cable
to the sensor.
Next
1.10 Service Wizard
04. 07. 2015 10:33
Disconnect it
and measure
its resistor.
Next
1.10 Service Wizard
04. 07. 2015 10:33
Could you detect
a short-circuit /
cable break?
YesNo
MALFUNCTION
The troubleshooting result is interrogated.
Continue via ›Yes‹ for the case that
the malfunction has been determined.
More detailed instructions
are available if required.
Acknowledge by pressing ›Next‹.
The controller here provides the troubleshoot-
ing instruction to check the connection cable.
Perform the measure in accordance
with the recommendation.
Acknowledge by pressing ›Next‹.
