MAINTENANCE AND TROUBLESHOOTING
E2 Troubleshooting Guide (cont.)
DIFFICULTY PROBABLE CAUSE SUGGESTION
777 Showing on Laser
Power Display
Not Enough Amperage Available
From Power Source
Front Panel Button Sticking
Footswitch Has An Electrical Short
Plug Unit Into a Non-overloaded
Outlet
Press Each Button To Verify It
Clicks Twice
Footswitch Needs to Be Rewired –
Call Endo Optiks Service
No White Light or
Intensity Not Adjustable
Footswitch Inadvertently
Depressed.
White Light Source Malfunction
Reposition Foot
Call Endo Optiks Service
Laser Power Indicator
Flashes “FFF” Or Goes
Out When Laser Is Fired
Footswitch Cable Is Twisted Where
It Enters The Footswitch
Internal Switch In Footswitch is
Defective
The footswitch is detected as
depressed on startup
Recycle the AC power
Call Endo Optiks Service
Call Endo Optiks Service
Remove foot from footswitch when
powering up system.
All displays show all “P’ The measured laser power is not
within the expected limits
Recycle the AC power
Call Endo Optiks Service
All displays show all “C” The current supplied to the laser is
not within the expected limits
Recycle the AC power
Call Endo Optiks Service
All displays show all “S”
or “5”
The Main Microcontroller does not
receive the proper
acknowledgement from the Slave
Microcontroller
Recycle the AC power
Call Endo Optiks Service
All displays show “d” When in pulse mode, the pulse
exceeds the duration selected by
20%.
Recycle the AC power
Call Endo Optiks Service
Operator Replaceable Parts
The following list of spare parts is available from Endo Optiks or Endo Optiks
distributors.
Part Name Description Part Number
Video Coupler E2 MicroProbe Video Coupler
OME 300Z – 10k Scopes
OME 300ZMG – 10k
Scopes
OME 170Z – 17k Scopes
OME 170ZMG – 17k
Scopes
OME 600ZMG – 6k
Scopes
Foot Switch MicroProbe Foot Switch
SW001, SW002, SW003
