Commissioning Deltabar PMD78B HART
22 Endress+Hauser
Setting the upper range value (pressure or scaled variable)
1. The desired pressure for the upper range value is present at the device.
2. Press the "Span" key for at least 3 s.
3. When the LED lights up briefly, the pressure present has been accepted for the upper
range value.
4. Does the LED on the electronic insert not light up?
Applied pressure for upper range value has not been accepted.
Wet calibration is not possible if the Scaled variable option has been selected in
the Assign PV parameter and the Table option has been selected in the Scaled
variable transfer function parameter.
Checking the settings (pressure or scaled variable)
1. Press the "Zero" key briefly (approx. 1 second) in order to display the lower range value.
2. Press the "Span" key briefly (approx. 1 second) in order to display the upper range value.
3. Briefly press the "Zero" and "Span" keys simultaneously (approx. 1 second) in order to
display the position offset.
Resetting the device
Press and hold the "Zero" and "Span" keys simultaneously for at least 12 seconds.
8.4.2 Commissioning with the commissioning wizard
In FieldCare, DeviceCare
1)
, SmartBlue and on the display, the Commissioning wizard is
available to guide the user through the initial commissioning steps. Commissioning is also
possible via AMS or PDM.
1. Connect the device with FieldCare or DeviceCare.
2. Open the device in FieldCare or DeviceCare.
The dashboard (homepage) of the device is displayed:
3. In the Guidance menu, click the Commissioning wizard to open the wizard.
4. Enter the appropriate value in each parameter or select the appropriate option. These
values are written directly to the device.
5. Click "Next" to go to the next page.
6. Once all the pages have been completed, click "End" to close the Commissioning wizard.
If the Commissioning wizard is cancelled before all the necessary parameters have been
configured, the device may be in an undefined state. In such situations, it is advisable to
reset the device to the factory default settings.
1) DeviceCare is available for download at www.software-products.endress.com. You must register in the Endress
+Hauser software portal to download the product.
