Parameter description (FF configuration program) Cerabar S/Deltabar S/Deltapilot S FOUNDATION Fieldbus
44 Endress+Hauser
Free Space/FREE_SPACE
Display
Index: 24
Data type: float
Access: read only
Displays the system memory (in percent) available for the execution of further function
blocks.
Input range:
0 to 100 %
Free Time/FREE_TIME
Display
Index: 25
Data type: float
Access: read only
Displays the free system time (in percent) available for the execution of further function
blocks.
Input range:
0 to 100 %
Shed Remote Cascade/
SHED_RCAS
Entry
Index: 26
Data type: Unsigned32
Access: auto, OOS
Enter the monitoring time for checking the connection between the fieldbus host system and
the PID function block in the RCAS block mode. On expiry of this monitoring time the PID
function block switches from the RCAS block mode to the block mode selected via the Shed
Options/SHED_OPT parameter.
Factory setting:
640000
1
/
32
ms
Shed Remote Out/
SHED_ROUT
Entry
Index: 27
Data type: Unsigned32
Access: auto, OOS
Enter the monitoring time for checking the connection between the fieldbus host system and
the PID function block in the ROUT block mode. On expiry of this monitoring time the PID
function block switches from the ROUT block mode to the block mode selected via the Shed
Options/SHED_OPT parameter.
Factory setting:
640000
1
/
32
ms
Fault State/
FAULT_STATE
Display
Index: 28
Data type: unsigned8
Access: read only
Current status display of the fault state of the Discrete Output function block.
Possibilities:
• Uninititalized
• Clear (fault state not active)
• Active (fault state active)
Set Fault State/
SET_FSTATE
Selection
Index: 29
Data type: unsigned8
Access: auto, OOS
Activate the fault state of the Discrete Ouput function block manually. → See also this Table,
Clear Fault State/CLR_FSTATE parameter description.
Possibilities:
• Uninititalized
•Off
• Set (the fault state is enabled)
Clear Fault State/
CLR_FSTATE
Selection
Index: 30
Data type: unsigned8
Access: auto, OOS
Deactivate the fault state of the Discrete Ouput function block manually. →See also this
Table, Set Fault State/SET_FSTATE parameter description.
Possibilities:
• Uninititalized
•Off
• Clear (fault state is disabled)
Max Notify/
MAX_NOTIFY
Display
Index: 31
Data type: unsigned8
Access: read only
Displays the number of event reports supported by the device that can exist unconfirmed at
the same time. → See also this Table, Limit Notify/LIM_NOTIFY parameter description.
Limit Notify/
LIM_NOTIFY
Entry
Index: 32
Data type: unsigned8
Access: auto, OOS
Enter the maximum possible number of event reports that can exist unconfirmed at the same
time. This parameter is not evaluated by Deltabar S, Cerabar S and Deltapilot S.
Resource Block
Parameter Description
