Commissioning Nivector FTI26
22 Endress+Hauser
8.3.4 Function test
Carry out a function test while the device is in operation.
‣
Hold the test magnet against the marking on the housing for at least 2 seconds.
 This inverts the current switch status, and the yellow LED changes state. When the
magnet is removed, the switching status valid at that time is adopted.
If the test magnet is held against the marking for ≥ 30 seconds, the red LED will flash: The
device returns automatically to the current switch status.
The test magnet is included in the scope of delivery. It is also possible to cancel it .
N
Ser. no.:
Order code:
Ext. ord. cd.:
A0035882
 11 Position for test magnet on housing nameplate
