Commissioning Proservo NMS80
66 Endress+Hauser
7.6 Linking measured values to tank variables
Measured values must be linked to tank variables before they can be used in the Tank
Gauging application.
Depending on the application not all these parameters will be relevant in a given
situation.
Submenu: Setup → Advanced setup → Application → Tank configuration → Level
Parameter Defines the source of the following tank variable
Level source Product level
Water level source Bottom water level
Submenu: Setup → Advanced setup → Application → Tank configuration → Temperature
Parameter Defines the source of the following tank variable
Liquid temp source Average or spot temperature of the product
Air temperature source Temperature of the air surrounding the tank
Vapor temp source Temperature of the vapor above the product
Submenu: Setup → Advanced setup → Application → Tank configuration → Pressure
Parameter Defines the source of the following tank variable
P1 (bottom) source Bottom pressure (P1)
P3 (top) source Top pressure (P3)
