COMPONENT MAINTENANCE MANUAL
BA27
24-01-01
This document contains Data controlled by the U.S. Export Administration Regulations. Diversion or use contrary to U.S. law is prohibited
General Information
Battery Voltage: Nominal 24.0 Volts
Battery Weight: 6.577 Kg Max. (14.5 lbs)
Dimensions: Overall Height 115.00 mm Max. (4.528")
Overall Width 92.00 mm Max. (3.622")
Overall Length 324.00 mm Max. (12.756")
Handle Extension 35.60 mm Max. (1.402")
Connector: ITT Cannon DPXBMA-10-34S-0015
Rated Capacity: 5 ampere-hours at the one hour rate
Monobloc Case Material: ABS Cycolac Grade G151
Battery Case Material: 1.2 mm thick NS4 (Al/MgP
2
P)
Leading Particulars
Figure 3
Page T-1
June 09/06
Page 6
June 09/06
