19
NOTE:
Please do not make the PV panel positive or negative grounded.
Figure 16: use a multimeter to measure module array voltage
!
WARNING!
PV module voltage is very high which belongs to dangerous voltage range,
please comply with electric safety rules when connecting.
!
WARNING!
When there is something wrong with module arrays, modules can be connected
with PV grid-tied inverter only after eliminating these problems.
