Engcon EC233 - Quick Hitch Greasing

6 Maintenance
IMPORTANT
In winter, a higher system pressure is required for tiltrotator
lubrication.
IMPORTANT
Check regularly that new grease is supplied to the tiltrotator.
6.4.2. Greasing the quick hitch
Grease quantity: 3-4 pump strokes per nipple.
Grease nipples on both sides, applies to all examples.
The arrows show the location of the grease nipples.
Example, S80
Example, S70
Figure 26.
Figure 27.
Example, HS
Example, ECPUP
Figure 28.
Figure 29.
42
