Engcon EC233 - Warning Decals on Product; Symbol Legend

8 Decals
8.2.1.2. 9000157
Figure 41. Warning decal to the right of operator.
8.2.2. Warning decals on product
8.2.2.1. 980101
Figure 42. Warning decal on the tilt cylinder.
8.2.2.2. 9000338
WARNING
Risk of injury
Make sure locking cylinder is in its
maximum extended position before
removing locking hook.
9000338-B
Figure 43. Warning decal on locking cylinder.
8.2.3. Symbol legend
Important to subtract tiltrotator weight when calculating lifts.
Take care when handling long objects. Bear in mind inertia and the
extended risk area when handling long objects.
55
