Engcon EC233 - Integrated Grab Cassette Specifications

9 Technical data
***Standard configuration
****If equipped with integrated grab
9.2. Integrated grab cassette
Figure 45.
Figure 46.
Max centre of gravity displacement 150mm.
Description
GR05
GR10
GR20B
GR30
GR20RR/
R2
Widest grab width
(A)
mm
350
610
820 - 950
1,080
820
Width (B)
mm
200
270
350
440
380
Length (C)
mm
585
760
910
980
*
Clamping force (tip
- tip) at 21 MPa
kg
1,654
1,497
2,234
1,956
1,750
Max load
kg
1,000
1,500
2,000
2,200
3,000
Weight
kg*
50
70
85
148
140
Max hydraulic
pressure
MPa
22
22
22
22
22
Table 22.
*Depending on attachment
See separate user manual for detachable GRD. Also available on the
website or by contacting engcon.
