1.6 Understanding the ENH210 LEDs
The rear of the ENH210 has two groups of LEDs. One group, labeled INDICATORS, shows the
status of the device. The second group, LINK QUALITY, shows the strength of the link
between the ENH210 and the network. The following table describes the ENH210 LEDs.
LED Color Mode Status
Power
Green
OFF= ENH210 is not receiving power.
ON= ENH210 is receiving power.
LAN1
LAN2
Green(Main)
Orange(Secondary)
OFF = ENH210 is not connected to the network.
ON = ENH210 is connected to the network, but not sending or
receiving data.
Blink = ENH210 is sending or receiving data.
WLAN
Green
Access Point
or Client
Bridge Mode
OFF = ENH210 radio is off and the device is not
sending or receiving data over the wireless LAN.
ON = ENH210 radio is on, and the device is not
sending or receiving data over the wireless LAN.
Blink = ENH210 radio is on, and the device is
sending or receiving data over the wireless LAN.
Link Quality
See Status column
Access Point
or Client
Bridge Mode
Shows the strength of the link between the
ENH210 and the network.
G = good quality (green).
Y = medium quality (yellow).
R = poor or no link (red).
