Physical Interface-EnStation5-ACv2/EnStationACv2
Dimensions and Weights
EnStation5-ACv2/EnStationACv2
Dimension: 190mm (7.48”)
Height: 38mm (1.9”)
Weight: 527g (1.16 lbs)
1 WLAN Signal LED: Applied on Client Bridge/WDS
(1) Red: Weak Signal: Connecting quality is bad.
(2) Yellow: Connecting quality is Normal.
(3) Green: Connection quality is Good.
2 LAN(PoE) Signal LED
3 LAN Signal LED of the 2nd Port
4 Power Signal:
5 LAN Port 1: Gigabit Ethernet port for RJ-45 cable.
6 LAN Port 2: Gigabit Ethernet port for RJ-45 cable.
5
4
1
6
2
3
