Checking the LEDs
3-4 Troubleshooting
MGR LED
TheMGRLEDindicateswhethertheswitchisoperatingasamemberorasthemanagerofthe
stack,asdescribedinTable 3‐1.
RPS LED
TheRPSLEDindicatesthestateoftheinternalpowersupplyandwhetheraredundantpower
supplyisprovidingpower,as describedinTable 3‐2.
Table 3-1 MGR LED Definitions
Color State Recommended Action
Off Switch is operating as a member in the
stack.
None.
Green Solid. Switch is operating as the manager
of the stack.
None.
Table 3-2 RPS LED Definitions
Color State Recommended Action
Off Connected RPS not in use. None.
Internal power supply failed. If an RPS is connected to the switch, it
should be providing power. Perform the
following:
1. Ensure the RPS is powered on.
2. Ensure that the AC power cord to the RPS
is plugged in correctly and that there is
power at the AC power source.
3. Replace the power cord with a known
good one.
4. Ensure the DC power cord from the RPS
to the switch is plugged in correctly.
5. If the problem persists, contact
Enterasys Networks for technical support.
Amber Solid. The switch internal power supply
failed, and the RPS is providing the proper
power to the switch.
None.
