Section 5 MODBUS I/O 28
Variable Channel Address Type Description
Status register 3 Read outputs [11] %IW22 WORD READ 16#900B (= 36875)
End of count 0 Bit 0 %IX22.0 BOOL Bit 48
End of count 1 Bit 1 %IX22.1 BOOL Bit 49
End of count 2 Bit 2 %IX22.2 BOOL Bit 50
End of count 3 Bit 3 %IX22.3 BOOL Bit 51
End of count 4 Bit 4 %IX22.4 BOOL Bit 52
End of count 5 Bit 5 %IX22.5 BOOL Bit 53
End of count 6 Bit 6 %IX22.6 BOOL Bit 54
End of count 7 Bit 7 %IX22.7 BOOL Bit 55
Reserved Bit 8 %IX23.0 BOOL
Reserved Bit 9 %IX23.1 BOOL
Reserved Bit 10 %IX23.2 BOOL
Reserved Bit 11 %IX23.3 BOOL
Reserved Bit 12 %IX23.4 BOOL
Reserved Bit 13 %IX23.5 BOOL
Reserved Bit 14 %IX23.6 BOOL
Reserved Bit 15 %IX23.7 BOOL
Status register 4 Read outputs [12] %IW24 WORD READ 16#900C (= 36876)
End of electrode 0 Bit 0 %IX24.0 BOOL Bit 64
End of electrode 1 Bit 1 %IX24.1 BOOL Bit 65
End of electrode 2 Bit 2 %IX24.2 BOOL Bit 66
End of electrode 3 Bit 3 %IX24.3 BOOL Bit 67
End of electrode 4 Bit 4 %IX24.4 BOOL Bit 68
End of electrode 5 Bit 5 %IX24.5 BOOL Bit 69
End of electrode 6 Bit 6 %IX24.6 BOOL Bit 70
End of electrode 7 Bit 7 %IX24.7 BOOL Bit 71
Reserved Bit 8 %IX25.0 BOOL
Reserved Bit 9 %IX25.1 BOOL
Reserved Bit 10 %IX25.2 BOOL
Reserved Bit 11 %IX25.3 BOOL
Reserved Bit 12 %IX25.4 BOOL
Reserved Bit 13 %IX25.5 BOOL
Reserved Bit 14 %IX25.6 BOOL
Reserved Bit 15 %IX25.7 BOOL
Status register 5 Read outputs [13] %IW26 WORD READ 16#900D (= 36877)
Tip dress 0 Bit 0 %IX26.0 BOOL Bit 80
Tip dress 1 Bit 1 %IX26.1 BOOL Bit 81
Tip dress 2 Bit 2 %IX26.2 BOOL Bit 82
Tip dress 3 Bit 3 %IX26.3 BOOL Bit 83
Tip dress 4 Bit 4 %IX26.4 BOOL Bit 84
Tip dress 5 Bit 5 %IX26.5 BOOL Bit 85
Tip dress 6 Bit 6 %IX26.6 BOOL Bit 86
Tip dress 7 Bit 7 %IX26.7 BOOL Bit 87
Reserved Bit 8 %IX27.0 BOOL
Reserved Bit 9 %IX27.1 BOOL
Reserved Bit 10 %IX27.2 BOOL
Reserved Bit 11 %IX27.3 BOOL
Reserved Bit 12 %IX27.4 BOOL
Reserved Bit 13 %IX27.5 BOOL
Reserved Bit 14 %IX27.6 BOOL
Reserved Bit 15 %IX27.7 BOOL
