Section 5 MODBUS I/O 29
Variable Channel Address Type Description
Status register 6 Read outputs [14] %IW28 WORD READ 16#900E (= 36878)
Prewarn 0 Bit 0 %IX28.0 BOOL Bit 96
Prewarn 1 Bit 1 %IX28.1 BOOL Bit 97
Prewarn 2 Bit 2 %IX28.2 BOOL Bit 98
Prewarn 3 Bit 3 %IX28.3 BOOL Bit 99
Prewarn 4 Bit 4 %IX28.4 BOOL Bit 100
Prewarn 5 Bit 5 %IX28.5 BOOL Bit 101
Prewarn 6 Bit 6 %IX28.6 BOOL Bit 102
Prewarn 7 Bit 7 %IX28.7 BOOL Bit 103
Reserved Bit 8 %IX29.0 BOOL
Reserved Bit 9 %IX29.1 BOOL
Reserved Bit 10 %IX29.2 BOOL
Reserved Bit 11 %IX29.3 BOOL
Reserved Bit 12 %IX29.4 BOOL
Reserved Bit 13 %IX29.5 BOOL
Reserved Bit 14 %IX29.6 BOOL
Reserved Bit 15 %IX29.7 BOOL
Status register 7 Read outputs [15] %IW30 WORD READ 16#900F (= 36879)
Bus fail Bit 0 %IX30.0 BOOL Bit 112
Short circuit Bit 1 %IX30.1 BOOL Bit 113
Fan failure Bit 2 %IX30.2 BOOL Bit 114
Inverter not ready Bit 3 %IX30.3 BOOL Bit 115
LMI config. error Bit 4 %IX30.4 BOOL Bit 116
LMI error Bit 5 %IX30.5 BOOL Bit 117
Duty cycle limit Bit 6 %IX30.6 BOOL Bit 118
Reserved Bit 7 %IX30.7 BOOL
Reserved Bit 8 %IX31.0 BOOL
Reserved Bit 9 %IX31.1 BOOL
Reserved Bit 10 %IX31.2 BOOL
Reserved Bit 11 %IX31.3 BOOL
Reserved Bit 12 %IX31.4 BOOL
Reserved Bit 13 %IX31.5 BOOL
Reserved Bit 14 %IX31.6 BOOL
Reserved Bit 15 %IX31.7 BOOL
Pre-heat current (A) Read outputs [16] %IW32 DWORD READ 16#9010 (= 36880)
Main current (A) Read outputs [18] %IW36 DWORD READ 16#9012 (= 36882)
Post-heat current (A) Read outputs [20] %IW40 DWORD READ 16#9014 (= 36884)
Program number Read outputs [22] %IW44 WORD READ 16#9016 (= 36886)
Force
1
Read outputs [23] %IW46 WORD READ 16#9017 (= 36887)
1
value is multiplied by the scale factor (898.88 for kN or 4 for lbf
