MODBUS mapping
Variable Address Type Description
Weld programs 256 x 64 WORDS
Weld program 0 16#0000 (= 0) WORD ARRAY [0..63]
Weld program 1 16#0040 (= 64) WORD ARRAY [0..63]
Weld program 2 16#0080 (= 128) WORD ARRAY [0..63]
Weld program 3 16#00C0 (= 192) WORD ARRAY [0..63]
… … …
Weld program 254 16#3F80 (= 16256) WORD ARRAY [0..63]
Weld program 255 16#3FC0 (= 16320) WORD ARRAY [0..63]
Electrodes 8 x 64 WORDS
Electrode 0 16#4000 (= 16384) WORD ARRAY [0..63]
Electrode 1 16#4040 (= 16448) WORD ARRAY [0..63]
Electrode 2 16#4080 (= 16512) WORD ARRAY [0..63]
Electrode 3 16#40C0 (= 16576) WORD ARRAY [0..63]
Electrode 4 16#4100 (= 16640) WORD ARRAY [0..63]
Electrode 5 16#4140 (= 16704) WORD ARRAY [0..63]
Electrode 6 16#4180 (= 16768) WORD ARRAY [0..63]
Electrode 7 16#41C0 (= 16834) WORD ARRAY [0..63]
Calibration 8 x 64 WORDS
Calibration 0 16#5000 (= 20480) WORD ARRAY [0..63]
Calibration 1 16#5040 (= 20544) WORD ARRAY [0..63]
Calibration 2 16#5080 (= 20608) WORD ARRAY [0..63]
Calibration 3 16#50C0 (= 20672) WORD ARRAY [0..63]
Calibration 4 16#5100 (= 20736) WORD ARRAY [0..63]
Calibration 5 16#5140 (= 20800) WORD ARRAY [0..63]
Calibration 6 16#5180 (= 20864) WORD ARRAY [0..63]
Calibration 7 16#51C0 (= 20928) WORD ARRAY [0..63]
Configuration 1 x 64 WORDS
Configuration 16#6000 (= 24576) WORD ARRAY [0..63]
