Weld program parameters
Variable Channel Address offset Type Description
Weld program %IW0 WORD ARRAY [0..63]
Attributes Weld program [0] %IW0 WORD
Pre heat Bit 0 %IX0.0 BOOL 0 = off, 1 = on
Post heat Bit 1 %IX0.1 BOOL 0 = off, 1 = on
Pre-mode
Bit 2 %IX0.2 BOOL 00 = PHA, 01 = CCu,
11 = CCC
Bit 3 %IX0.3 BOOL
Main mode
Bit 4 %IX0.4 BOOL 00 = PHA, 01 = CCu,
11 = CCC
Bit 5 %IX0.5 BOOL
Post-mode
Bit 6 %IX0.6 BOOL 00 = PHA, 01 = CCu,
11 = CCC
Bit 7 %IX0.7 BOOL
Link mode Bit 8 %IX1.0 BOOL 0 = off, 1 = on
Repeat mode Bit 9 %IX1.1 BOOL 0 = off, 1 = on
Wait force Bit 10 %IX1.2 BOOL 0 = off, 1 = on
Force profile Bit 11 %IX1.3 BOOL 0 = off, 1 = on
Test force Bit 12 %IX1.4 BOOL 0 = off, 1 = on
Test pre-current Bit 13 %IX1.5 BOOL 0 = off, 1 = on
Test main current Bit 14 %IX1.6 BOOL 0 = off, 1 = on
Test post-current Bit 15 %IX1.7 BOOL 0 = off, 1 = on
Presqueeze time Weld program [1] %IW1 WORD 0 – 1999
Squeeze time Weld program [2] %IW2 WORD 0
–
1999
Pre-heat time Weld program [3] %IW3 WORD 0
–
1999
Pre-heat Weld program [4] %IW4 WORD 0
–
1999
Reserved Weld program [5] %IW5 WORD
Pre-current Weld program [6] %IW6 DWORD 0 – 500000
Cool1 time Weld program [8] %IW8 WORD 0 – 1999
Main heat time Weld program [9] %IW9 WORD 0
–
1999
Main heat Weld program [10] %IW10 WORD 0
–
1999
Reserved Weld program [11] %IW11 WORD
Main current Weld program [12] %IW12 DWORD 0 – 500000
Cool2 time Weld program [14] %IW14 WORD 0 – 1999
Pulsations Weld program [15] %IW15 WORD 1
–
99
Post-heat time Weld program [16] %IW16 WORD 0
–
1999
Post-heat Weld program [17] %IW17 WORD 0 – 1999
Reserved Weld program [18] %IW18 WORD
Post-current Weld program [19] %IW19 DWORD 0 – 500000
Hold time Weld program [21] %IW21 WORD 0 – 1999
Off time Weld program [22] %IW22 WORD 0
–
1999
Upslope time Weld program [23] %IW23 WORD 0
–
1999
Downslope time Weld program [24] %IW24 WORD 0
–
1999
Squeeze valves
1
Weld program [25] %IW25 WORD
Pre-heat valves
1
Weld program [26] %IW26 WORD
Cool1 valves
1
Weld program [27] %IW27 WORD
Upslope valves
1
Weld program [28] %IW28 WORD
Main heat valves
1
Weld program [29] %IW29 WORD
Cool2 valves
1
Weld program [30] %IW30 WORD
Downslope valves
1
Weld program [31] %IW31 WORD
Post-heat valves
1
Weld program [32] %IW32 WORD
Hold valves
1
Weld program [33] %IW33 WORD
Off valves
1
Weld program [34] %IW34 WORD
1
Weld program [nn] %IXnn.0.0 BOOL AV1 state 1 = ON
Weld program [nn] %IXnn.0.1 BOOL AV2 state 1 = ON
Weld program [nn] %IXnn.0.2 BOOL AV3 state 1 = ON
Weld program [nn] %IXnn.0.3 BOOL AV4 state 1 = ON
Weld program [nn] %IXnn.0.4 BOOL AV5 state 1 = ON
Weld program [nn] %IXnn.0.5 BOOL AV6 state 1 = ON
Weld program [nn] %IXnn.0.6 BOOL AV7 state 1 = ON
Weld program [nn] %IXnn.0.7 BOOL AV8 state 1 = ON
