Weld program parameters (continued)
Variable Channel Address offset Type Description
Squeeze force Weld program [35] %IW35 WORD 0 – 32767
2
Pre-heat force Weld program [36] %IW36 WORD 0 – 32767
2
Cool1 force Weld program [37] %IW37 WORD 0 – 32767
2
Upslope force Weld program [38] %IW38 WORD 0
–
32767
2
Main heat force Weld program [39] %IW39 WORD 0
–
32767
2
Cool2 force Weld program [40] %IW40 WORD 0 – 32767
2
Downslope force Weld program [41] %IW41 WORD 0 – 32767
2
Post-heat force Weld program [42] %IW42 WORD 0 – 32767
2
Hold force Weld program [43] %IW43 WORD 0
–
32767
2
Off force Weld program [44] %IW44 WORD 0
–
32767
2
Force low limit Weld program [45] %IW45 WORD 0
–
99 %
Force high limit Weld program [46] %IW46 WORD 0 – 99 %
Selected WAV Weld program [47] %IW47 WORD 0 – 7
Current low limit Weld program [48] %IW48 WORD 0 – 99 %
Current high limit Weld program [49] %IW49 WORD 0
–
99 %
Selected electrode Weld program [50] %IW50 WORD 0
–
7
Linked program Weld program [51] %IW51 WORD 0
–
255
Last pre-current Weld program [52] %IW52 DWORD 0 – 500000
Last main current Weld program [54] %IW54 DWORD 0 – 500000
Last post-current Weld program [56] %IW56 DWORD 0
–
500000
Reserved Weld program [58] %IW58 WORD
Reserved Weld program [59] %IW59 WORD
Reserved Weld program [60] %IW60 WORD
Attributes Weld program [61] %IW61 WORD
Inhibited Bit 0 %IX61.0 BOOL 0 = enable, 1 = inhibit
Motor valves
1
Weld program [62] %IW62 WORD
Reserved Weld program [63] %IW63 WORD
2
Divide value by 898.99 for kN. Divide value by 4 for lbf.
Electrode parameters
Variable Channel Address offset Type Description
Electrode %IW0 WORD ARRAY [0..63]
Attributes Electrode [0] %IW0 WORD
Enable counter Bit 0 %IX0.0 BOOL 0 = off, 1 = on
Enable tipdress Bit 1 %IX0.1 BOOL 0 = off, 1 = on
Enable stepper Bit 2 %IX0.2 BOOL 0 = off, 1 = on
Stop at endcount Bit 3 %IX0.3 BOOL 0 = off, 1 = on
Stop at endstep Bit 4 %IX0.4 BOOL 0 = off, 1 = on
Transformer Electrode [1] %IW1 WORD 0
–
7
Counter Electrode [2] %IW2 WORD 0
–
9999
Endcount Electrode [3] %IW3 WORD 0 – 9999
Dressings done Electrode [4] %IW4 WORD 0 – 9999
Max dressings Electrode [5] %IW5 WORD 0
–
9999
Stepper spots done Electrode [6] %IW6 DWORD Read only
Stepper % done Electrode [8] %IW8 WORD Read only
Stepper reset to Electrode [9] %IW9 WORD 0 – 9999
Stepper spots Electrode [10..19] %IW10..19 WORD 0 – 9999
Stepper delta H Electrode [20..29] %IW20..29 WORD 0 – 500 (% x 10)
Stepper delta I Electrode [30..39] %IW30..39 WORD 0
–
500 (% x 10)
Reserved Electrode[40]-[63]
