3 Installation Instructions STACK 710
24 (PC-000878-MA Issue 7, December 2021) ENVEA UK Ltd

0V
Blue
-
-
-
-
24V
Red
Screen
Screen

0V
Black
Comms B (RS485 D0)
Yellow
Comms A (RS485 D1)
Green
-
-
Screen
Screen
3.11.2 Method b: Direct sensor to control unit connection

0V
Blue (Connector A) +
Black (Connector C)
Comms B (RS485 D0)
Yellow (Connector C)
Comms A (RS485 D1)
Green (Connector C)
24V
Red (Connector A)


