Gobi-640-17µm and Gobi-384-25µm-GigE, CL, CXP Camera
Trigger-in delay
2.2 µs rising edge (SMA
trigger)
(2)
2.4 µs falling edge (SMA
trigger)
(2)
0.4 μs rising and falling
edge (CC1 trigger)
2.2 μs rising edge (SMA
trigger)
(2)
2.4 μs falling edge (SMA
trigger)
(2)
2.2 µs rising edge (SMA
trigger)
(2)
2.4 µs falling edge (SMA
trigger)
(2)
Trigger-in jitter 0.03 µs
Power consumption < 4.5W < 2W < 3.5W
Dimensions (W x H x
L)
(1)
49.0 x 49.0 x 79.0 mm
3
49.0 x 49.0 x 61.4 mm
3
49.0 x 49.0 x 69.4 mm
3
Camera weight
(1)
263 g 208 g 231g
Table 2-2 Gobi-640-GigE/CL/CXP camera specifications
(1)
Without Lens
(2)
With trigger-in voltage = 5V
The design and specifications for the products described above may change
without notice.
2.3. Gobi-384-25µm Detector Specifications
The detector specifications are summarized in Table 2-3.
Parameter Specification
Array Type a-Si micro-bolometer
# pixels 384 (W) x 288 (H)
Pixel pitch 25µm
Spectral Band 8-14 µm
NETD
(1) <60 mK @ 30°C with F/1 lens
(2) <80mK @ 30°C with F/1 lens
Detector Operating Mode Rolling Shutter Mode
Window of interest Yes – Higher frame rates possible for smaller windows
Exposure time range 1 – 70 µs
Pixel Operability >99%
Table 2-3 Gobi-384 detector specifications
