Envision Xenics Gobi-640-17mm User Manual

User Manual
Gobi-640-17µm and Gobi-384-25µm-GigE, CL, CXP Camera
4.3. Trigger Interface
Do not apply voltages to the trigger connector when it is configured in
Trigger-OUT mode, because this will damage the camera!
For the trigger interface, a SMA connector is foreseen.
The trigger interface can be configured either as Trigger-IN or Trigger-OUT. The following
settings can be customized:
• Trigger OUT
o Polarity:
 High
 Low.
o Width
o Delay.
• Trigger-IN
o Sensitivity
 Level
 Edge.
o Polarity:
 Low level / falling edge
 High level / rising edge.
o Delay
o Trigger skip-count.
More information on the trigger configuration can be found in (Ref. 4).
!
www.envision.co.kr •Supporting your Vision
(주)앤비젼 서울시 금천구 가산동 550-1 IT캐슬 1동 603호 (153-768)
Tel. 02. 2624. 5503 Fax. 02. 2082. 6427 e-mail. sales@envision.co.kr
