Gobi-640-17µm and Gobi-384-25µm-GigE, CL, CXP Camera
2.4. Gobi-384-25µm GigE & CL Camera Specifications
The Gobi-384 specifications are listed in Table 2-4.
Feature GigE CL
Frame rate (full frame) 84 Hz
Shutter Yes
Cooling No
A/D conversion resolution 16 bit
Input Voltage 12V±10%
Ambient operating
temperature
-40°C to 60°C
Storage Temperature -45 to 85°C
Vibration 5g (20 to 2000 Hz), according to MIL-STD883J
Shock 40g, 11ms, according to MIL-STD810G
Electrical interface
GigE Vision (image acquisition
and camera control)
Camera Link (image acquisition
and camera control)
Trigger In or out via SMA In or out via SMA or CL-CC1
Trigger-in delay
2.5 μs rising edge (SMA trigger)
(2)
2.7 μs falling edge (SMA trigger)
(2)
0.7 μs rising and falling edge
(CC1 trigger)
2.5 μs rising edge (SMA trigger)
(2)
2.7 μs falling edge (SMA trigger)
(2)
Trigger-in jitter 0.05 µs
Power consumption < 4.5W < 2W
Dimensions (W x H x L)
(1)
49.0 x 49.0 x 79.0 mm
3
49.0 x 49.0 x 61.4 mm
3
Camera weight
(1)
263 g 208 g
Table 2-4 Gobi-384-GigE&CL camera specifications
(1)
Without Lens
(2)
With trigger-in voltage = 5V
The design and specifications for the products described above may change
without notice.
