1.3 Standard Version Specifications
Technical specification details in accordance with VDI2198. Technical modifications
and additions reserved.
1.3.1 Performance data for standard trucks
Item
Description
CQD12R/RF
Unit
Drive unit
Battery
Operator type
Seated
Q
Load capacity
2645
lb.
c
Load center
23.6
in.
Travel speed, laden/ unladen
5.0/5.2
mph
Lifting speed, laden/ unladen
51.2/79.6
fpm
Lowering speed, laden/ unladen
69.65/53.7
fpm
Reach speed, laden/ unladen
19.9/19.9
fpm
Max. gradeability, laden/unladen
8/10
%
Service weight （include battery）
SEE Form 2
lb.
Axle loading, fork advanced, unladen driving
side/loading side
2264/2171
lb.
Axle loading, fork retracted, unladen driving
side/loading side
2828/1020
lb.
Axle loading, fork advanced, laden driving
side/loading side
862/6333
lb.
Axle loading, fork retracted, laden driving
side/loading side
2590/4605
lb.
Drive motor rating S2 60 min.
5.3
hp
Lift motor rating at S3 15%
11
hp
Tyre type driving wheels/loading wheels
Polyurethane
Type of drive unit
AC
Steering type
Electronic
Park brake type
Electromagnetic
Battery voltage/nominal capacity K5
SEE Form 4.1
V/Ah
Sound pressure level at the driver’s ear
75
dB(A)
