3.4.2 Travel, Steering, Braking
Do not drive the truck unless the panels are closed and properly locked.
When you start up the truck the drive pedal must be applied.
1.Driving
• Insert the key in the key switch and turn it to the “ON” position .
• Pull up the emergency brake switch .
• Use the travel switch (4) to select the required driving direction.
Forward = the drive direction (V), the main travel direction.
Back = the load direction (R) .
• apply the drive pedal (6).
• The travel speed is governed by the accelerator (5).
• Use steering wheel (1) to steer the truck in the required direction.
Warning!
• The truck can only be moved with or without a load when the mast support
is retracted, the mast tilted back and the load handler lowered.
• You should only travel in the load direction (R) for shunting and lifting or
depositing a load.
