4.4 Charging the battery
• Expose the battery(See 4.3 Expose the battery ).
Safety regulations for Charging
• Please charge in the well-ventilated and
appointed site.
• Mark ‘no smoking’ on charging.
• ahead of charging，please examine wire and
pin whether good or not. When wire and pin are
damaged，please do not charge.
• When charging, the tops of the battery cells
must be exposed to provide sufficient
ventilation.
• In charging，electrical source switch or battery
pin are not close，or，which destroys pin and electrical units as a rule， first press the
stopping button on the charger，then unfix the pin.
It is essential to follow the safety regulations of the battery and charging station
manufacturers.
4.5 Battery removal and installation
• Expose the battery(See 4.3 Expose the battery ).
• Place the battery plug or the
battery cable in such a way
that they will not get caught on
the truck when the battery is
removed.
• The hooks(1) must be
attached to the eyes of the
battery in such a way.
• Lift the battery clear and
move out to the side.
• Installation is in the reverse
order of operations.
Warning! To prevent short circuits, batteries with exposed terminals or connectors
must be covered with a rubber mat. When replacing a battery with a crane, make sure
the crane has sufficient capacity (see battery weight on the battery data plate on the
container). The lifting gear must exert a vertical pull so that the battery container is not
compressed. Hooks must be fitted in such a way that when the crane lifting harness is
slackened, they do not fall onto the battery cells.
