3.2.1
Tyre size, driving
wheels(diameter×width)
mm
Ф210x70
3.3.1
Tyre size, loading
wheels(diameter×width)
mm
Ф80x60(Ф74x88)
3.4
Tyre size, caster
wheels(diameter×width)
mm
/
3.5
Wheels, number driving,
caster/loading (x=drive
wheels)
mm
1x,2/4(1x,2/2)
3.6
Track width, front,driving side
b10 mm
/
3.7
Track width,rear,loading side
b11 mm
410/(535)
Dimensions
4.4
Lift height
h3 mm
105
4.9
Height drawbar in driving
position min./max.
h14 mm
750/1190
4.15
Lowered height
h13 mm
82
4.19
Overall length
l1 mm
1550
4.20
Length to face of forks
l2 mm
325
4.21
Overall width
b1/ b2 mm
695(590)
4.22
Fork dimensions
s/ e/ l mm
55x150x1150
4.25
Distance between fork-arms
b5 mm
560(685)
4.32
Ground clearance, center of
wheelbase
m2 mm
25
4.34.1
Aisle width for pallets 1000 ×
1200 crossways
Ast mm
2160
4.34.2
Aisle width for pallets 800 ×
1200 lengthways
Ast mm
2025
4.35
Turning radius
Wa mm
1360
Performance data
5.1
Travel speed, laden/ unladen
km/ h km/h
4/4.5
5.2
Lifting speed, laden/ unladen
m/ s
0.017/0.020
