REV. 09/2022
13
B
Rightward
Leftward
2.Steering
Rotate the operation hand shank leftward or
rightward as required.
Braking area
Braking area
3.Braking
Mechanical operating brake
The truck is braked when the operating handle
is released.
The mechanical brake engages when the tiller
is positioned in Braking area.
Reverse braking
Braking can be accomplished by changing
the direction of travel.
Press the reverse switch (1) in the opposite
direction until the truck comes to a stop,
then release the drive switch.
1
Open the drive switch; if the drive
switch cannot quickly return to the initial
position or resets very slowly, identify the
cause and rectify the fault.
CAUTION
If the control handle moves slowly into
the brake position, identify the cause
and rectify the fault. If necessary,
replace the gas spring!
CAUTION
