ep RPL201 - Truck Overview and Controls; Component Identification

REV. 09/2022
5
B
1.2 Overview
,
Display,Manipulation
1.2.1 Truck overview
1 Control Handle 8 Forks
2 Key switch 9 Load wheels
3 Side arms 10 Emergency stop switch
4 Hydraulic unit 11 Operator platform
5 Drive wheel
6 Caster
7 Display instrument
1
2
7
5
11
6
8
9
10
3
4
