Intended use
The truck is designed for transporting the loads stated in the nameplate.
In particular we refer to:
• the safety rules of your trade association.
• In accordance with the special provisions for driving on public roads specied by national
specications.
• Other local regulations.
The rules for the intended and approved use of industrial trucks must be followed under all
circumstances by the responsible persons, especially by the operator and service personnel.
The user, and not EP, is responsible for any danger arising from applications not authorised by the
manufacturer.
If you want to use the truck for applications not mentioned in this manual, please rst contact your
authorised dealer.
No changes, particularly no modications and additions, may be made to the truck without the
approval of the manufacturer.
These trucks consists of robust steel chassis and is driving on a traction wheel and 2 load wheels.
Caster wheels provide for good stability even with high loads.
The truck will be stopped by a regenerative service brake and hold by an automatic electromagnetic
parking brake in it’s parking position.
The load is lifted by a hydraulic cylinder that activates a lifting shaft that transmits the lifting
movement by a push-rod to the load wheels.
The control handle is used for smooth steering and control of drive speed, lifting and lowering,
braking and the horn without changing the position of the hand. The long tiller shaft allows
e󰀨ortless steering and a safe distance to the truck. A gas spring returns the control handle always
into a vertical position that activates the brake automatically.
An emergency reverse switch on the control head protects the operator from being squeezed by
the truck in conned spaces.
An electronic controller operates all electric functions and guaranties safety.
A key switch secures the truck from unauthorized use.
The ergonomic design of the truck guaranties safe and easy operation.
Technical description
This manual is used for operation and maintenance, the detail parameters, size and specication
s in context is only for reference , the real parameters will depend on sale les.
Manual pictures for reference only, the real car shall prevail, and shall not a󰀨ect the manual use.
Manual pictures only sign for one of the models in this series models.
Schematic views
