ep RPL201 - Page 46

REV.12/2020
2
E
3.3.1 Tyre size, loading
wheels(diameter×width)
mm Ф85x70 / Ф83x115 Ф85x70 / Ф83x115
3.4 Tyre size, caster
wheels(diameter×width)
mm Ф130x55 Ф130x55
3.5 Wheels, number driving,
caster/loading (x=drive
wheels)
mm 1x,2/4(1x,2/2) 1x,2/4(1x,2/2)
3.6 Track width, front,driving
side
b10 mm 510 510
3.7 Track width,rear,loading
side
b11 mm 370/515 370/515
Dimensions
4.4 Lift height h3 mm 120 120
4.9 Height drawbar in driving
position min./max.
h14 mm 1075 / 1288 1075 / 1288
4.15 Lowered height h13 mm 85 85
4.19 Overall length l1 mm 1954/2024 1954/2024
4.20 Length to face of forks l2 mm 804 804
4.21 Overall width b1/
b2
mm 734 734
4.22 Fork dimensions s/ e/ l mm 55×170×1150 55×170×1220 55x170x1150
55×170×1220
4.25 Distance between fork-
arms
b5 mm 540/685 540/685
4.32 Ground clearance, center
of wheelbase
m2 mm 30 30
4.34.1 Aisle width for pallets 1000
× 1200 crossways
Ast mm 2606 2606
4.34.2 Aisle width for pallets 800
× 1200 lengthways
Ast mm 2463 2463
4.35 Turning radius Wa mm 1806/1826 1806/1826
