8
DC Input Terminal Positive
RS485 communication port
(4)
DC input voltage range
(1)
USB output port (5VDC/1A)
DC Input Terminal Negative
Working indicator(green)
(6)
(1) Input rated voltage
12V system input voltage range is 10.8～16V；
24V system input voltage range is 21.6～32V；
48V system input voltage range is 43.2～60V。
(2) Fan Ventilation
When the heat sink temperature is higher than 50℃ or internal
temperature is higher than 50℃, the fan will turn on automatically.
When the heat sink temperature is lower than 40℃ and internal
temperature is lower than 40℃, the fan will turn off automatically.
(3) AC Outlet (optional)
Universal
