10. Technical Specification
Item
IP350-12
IP350-22
IP350-11
IP350-21
Rated Input Voltage
12VDC
24VDC
12VDC
24VDC
Input Voltage Range
10.8～16VDC
21.6～32VDC
10.8～16VDC
21.6～32VDC
Input surge voltage
＜32VDC
＜44VDC
＜32VDC
＜44VDC
Output Voltage
220VAC(±5%)
230VAC(-7%～+5%)
110VAC(±5%)
120VAC(-10%～+5%)
Output Frequency
50/60±0.1Hz
Output Continuous
Power
280W
Output Power 15 min.
350W
Surge power
750W
Power factor
0.2-1(VA lower than output continuous power)
Output Wave
Pure sine wave
Distortion THD
THD≤3%
①
THD≤5%
①
Max. Efficiency
91%
92%
90%
91%
No-load current
＜0.7A
＜0.5A
＜0.7A
＜0.5A
USB Output Port
②
5VDC/Max.1A
Binding post
Φ6mm
Overall dimension
214×105.5×57.7mm
Mounting dimension
185.5×76.7mm
Mounting hole size
Φ4.2mm
Net weight
1.0kg
①Test condition: Rated Input Voltage, Output Continuous Power, Resistive load.
②Conventional products don’t have this port; the port is optional.
