1) Press the ENTER button again to display the
current voltage value.
2) Press the SELECT button to modify the parameter
(short press to increase 0.1V, long press to
decrease 0.1V).
3) Press the ENTER button to confirm and enter the
next parameter.
Press the SELECT button to modify the switch status.
Note: It exists automatically from the current interface
after no operation of more than 10S.
The SYS value can only be modified under the non-lithium "USE" type. That is, the battery type
is Sealed, Gel, or Flooded before entering the "USE" type, the SYS value can be modified; if it is
lithium battery type before entering the "USE" type, the SYS value cannot be modified.
Only the above battery parameters can be set on the local controller, and the remaining battery
parameters follow the following logic (the voltage level of 12V system is 1, the voltage level of 24V
system is 2).
Battery type
Battery
parameters
Over voltage
disconnect voltage
Over voltage reconnect
voltage
Equalize charging
voltage
Boost reconnect
charging voltage
Under voltage warning
reconnect voltage
Under voltage warning
voltage
Discharging limit
voltage
④ Battery voltage parameters
Measure the parameters in the condition of 12V/25ºC. Please double the values in the 24V
