• Table Focus Oset [cnts]
● The distance in table encoder counts from the top crash switch, to the laser focus position
• RHS Y Skew [cnts]
● The number of encoder counts to skew the right hand side of the Y axis aer homing
● Requires “Home Axis” to take eect
• Air Assist Delay [s]
● The number of seconds to delay turning ON and turning OFF the air assist before and aer a job
finished
● Format is as follows: ON,OFF
- 230 -
APPENDIX C: SYSTEM CALIBRATION
