Additional Color Mapping Notes
When color mapping is used, the laser always starts from the top color in the Processes Tab and then
descends through the remaining colors. You can rearrange the order of the process by clicking and
dragging them up and down in the Processes Tab.
Color Mapping in Combined Mode
Aer all of the raster objects have been engraved, the vector objects will be vectored in the order they
appear in the Processes Tab.
Split by Hairline
When you print your file to the laser, you can manually select to split your processes by hairline.
1. Click on the process and select “Split by Hairline”.
2. All hairline vector lines will be grouped into a separate process.
- 70 -
SECTION 5: THE LASER DASHBOARD
