15
Ref� No� Product No� Qty Description Specification
1 87003838 1 Guide
2 87004045 1 Spindle Details p. 21
3 87003865 1 Splash guard
4 87004736 1 Holder complete
5 87004744 1 Strip
6 87003862 1 Rubber mat
7 87003907 1 Motor shelf
8 87003932 1 Pulley
9 87003705 2 Shaft
10 87001667 4 Bracket
11 87000783 1 Pulley 50 Hz
12 87003431 4 Socket
13 87003512 1 Pulley 60 Hz
14 87003566 1 Splash guard Inner
15 87000503 8 Washer BRB 5.3
16 87000131 10 Washer BRB 8.4
17 87000167 10 Washer BRB 10.5
Ref� No� Product No� Qty Description Specification
18 87000430 4 Washer BRB 13
19 87000185 10 Nut M10
20 87000504 2 Nut M5
21 87000449 4 Screw 10x35
22 87001678 4 Screw 12x40
23 87000186 2 Screw 8x40
24 87000810 8 Screw 8x65
25 87004634 8 Screw 5x12
26 87003938 1 Flat belt
27 87000203 8 Clip
28 87001676 4 Circlip Sgh 40
29 87003430 2 Screw 6 X 8
30 87000462 4 Bellows
31 87001671 4 Ball bushing Lbbr 30
32 87001621 3 Screw 10 X 70
33 87001489 1 Spring 2.5x12.5x17.9
34 87003890 1 Electric motor
Grinding unit
