5.5 Removing the hydraulic
attachment from the carrier
n
You need an assistant to remove the hydraulic at-
tachment.
n
Agree on hand signals with your assistant, to enable
him to help you move the boom.
WARNING Injury by impacts
A sudden movement of the carrier may cause your as-
sistant to be hit and injured by the boom or the hydraulic
attachment.
u Only move the boom very slowly and in a controlled
manner while an assistant is within the danger zone.
u Always keep sight of your assistant.
n
Put out the assembly stand within reach of the boom.
WARNING Unexpected movement
Sudden movements of the carrier may cause serious in-
jury.
u Secure the carrier such that it cannot move unex-
pectedly.
u Observe the carrier manufacturer’s instructions.
WARNING Hydraulic hose flailing about
Pressurised hydraulic hoses will flail about when bolted
connections have come loose or have been loosened. A
hydraulic hose flailing about may cause serious injuries.
u Depressurise the hydraulic system before discon-
necting a hydraulic hose (see chapter Depressuris-
ing the hydraulic system).
WARNING Hot parts
The cutter drums, hoses, pipes and fittings become very
hot during operation. Touching them may lead to burns.
u Never touch hot parts.
u If you have to carry out activities where you have to
touch the parts, wait for them to cool down first.
n
Position the drum cutter carefully on the assembly
stand.
n
Close all shut-off valves in the installation at the
boom if no quick couplings are used.
n
Disconnect the hose lines to and from the hydraulic
attachment at the boom side.
n
Close off all open hose ends.
WARNING Metal chips shooting off
When hammering out bolts, chips may shoot off and
cause serious eye injuries.
u Wear safety glasses when hammering out the
bolts.
n
Remove the bolt locks from the stick and linkage
bolts.
n
Drive out the linkage bolt with a steel arbor and a
hammer.
n
Switch on the carrier.
n
Retract the bucket cylinder.
n
Drive out the stick bolt with a steel arbor and a ham-
mer.
n
Move the carrier stick out of the adapter plate.
n
Secure the drum cutter on the assembly stand.
n
Remove the fastening screws of the adapter plate.
n
Lift the adapter plate with a suitable lifting equipment
and put it down on timber support blocks.
n
Save the fastening screws and the pairs of lock
washers for future use.
