Safety and operating instructions
© Anbaufräsen PC GmbH | 3390 5221 01 | 2020-09-07
Original Instructions
61
The bolt connections of drum cutters are subjected to very high loads.
n
Tighten any loose connections so that the tightening torques are maintained.
ER 450 L ER 600 L ERL 700
Connection point Interval Type of spanner / size
Tightening torque
Adapter plate
(fixing bolts)
daily Allen key
17 mm (0.67 in.)
390 Nm (288 ft lbs)
19 mm (0.75 in.)
700 Nm (516 ft lbs)
Rotatable upper part
(fixing bolts)
in case of repair Allen key / 14 mm (0.55 in.)
180 Nm (133 ft lbs)
-
Cutter drum
(fixing bolts)
if necessary Allen key
14 mm (0.55 in.)
300 Nm (221 ft lbs)
17 mm (0.67 in.)
560 Nm (413 ft lbs)
-
Overpressure cover
(fixing bolts)
in case of repair open-ended wrench
19 mm (0.75 in.)
75 Nm (55 ft lbs)
30 mm (1.18 in.)
400 Nm (295 ft lbs)
Hydraulic ports*
pressure line and
tank line
leakage oil
weekly Hand-tighten and then tighten a quarter turn with the wrench
Cover
(fixing bolts)
if necessary Allen key
6 mm (0.24 in.)
40 Nm (30 ft lbs)
14 mm (0.55 in.)
180 Nm (133 ft lbs)
* valid only for metric standard hose set
