10
Reversing the Door Swing
Tools required: Philips style screwdriver / Flat bladed screwdriver / Hexagonal spanner
1. Remove the upper hinge cover, screws
and upper hinge. Lift the upper door and
place it on a padded surface to prevent
from being scratched. Remove the screw
hole cover from the opposite side and
keep it for future use. For the right side,
use the screw hole cover from the plastic
bag.
2. Remove the screw and stop block from
the bottom of the upper door and move
it to the opposite side. Remove also
the door stopper and keep it for future
use. For the opposite side, use the door
stopper for left side. Screw tightly.
• Ensure the unit is unplugged and empty.
• To take the door o it is necessary to tilt the unit backwards. You should rest the
unit on something solid, e.g. a chair just below the top panel.
• All parts removed must be saved to do the reinstallation of the door.
• Do not lay the unit at as this may damage the coolant system.
• We recommend that 2 people handle the unit during assembly.
• If you want to have the door swing reversed, we recommend that you contact a
qualied technician. You should only try to reverse the door yourself if you believe
that you are qualied to do so.
After lifting the hinge cover, be
sure to disconnect the electrical
connector.
Screw hole cover has left and right
side. The screw hole cover packed
as an accessory is for the right side.
Door stopper has left and right
side. The door stopper packed as an
accessory is for the left side.
