11
3. Remove the middle hinge. Lift the lower
door and place it on a padded surface to
prevent from being scratched.
4. Remove the screw and stop block from
the bottom of the lower door and move
it to the opposite side. Remove also
the door stopper and keep it for future
use. For the opposite side, use the door
stopper for left side. Screw tightly.
5. Remove both levelling feet and bottom
hinge.
6. On the bottom hinge, reverse the
position of the bottom hinge pin. Tighten
the pin securely.
Door stopper has left and right
side. The door stopper packed as an
accessory is for the left side.
• Do not lay the unit at as this
may damage the coolant system.
• During door reversal, when
swapping the position of the
bottom hinge or adjusting the
levelling feet, tilt the unit. Do not
lay the unit at.
