INSTALLATION
12
GB
7. Screw the bottom hinge and levelling
feet tightly on their new position.
8. Remove the middle hinge hole covers
and swap their position with the middle
hinge. Reverse the middle hinge.
9. Place the bottom hole of the lower door
onto the bottom hinge pin. Insert the
middle hinge pin into the upper hole of
the lower door. Tighten the pin securely.
Screw the middle hinge tightly. Cover the
remaining holes with the hole covers.
10. Place the bottom hole of the upper door
onto the middle hinge pin. Take out the
electrical connector from the top left side
of the door. On the top right side of the
door, insert the electrical connector into
the door.
Ensure the lower door is aligned
horizontally and vertically, so that
the seals are closed on all sides
before nally tightening the pin.
