13
11. Connect the electrical connectors.
Reverse the upper hinge and pin position.
Insert the upper hinge pin into the upper
hole of the upper door. Tighten the pin
securely. Screw the upper hinge tightly.
12. Cover the upper hinge with the upper
hinge cover.
Ensure the upper door is aligned
horizontally and vertically, so that
the seals are closed on all sides
before nally tightening the pin.
