Testing the Printer
-
3.
Move the left edge guide until it locks in place next to the
arrow guide mark. Then adjust the right edge guide to match
the width of your paper.
CAUTION: Run the self test using paper at least 210 mm
(8
i
inches) wide for the LQ-870 or 360 mm (14 inches)
wide for the LQ-1170; otherwise the print head prints
directly onto the platen.
-
4.
Insert a sheet of paper down between the edge guides until it
meets resistance. After about two seconds, the printer loads the
-
paper automatically and starts the self test.
-.
1-12
Setting Up the Printer
