Appendix
Rev. A
A-4
A.3 EEPROM Address Map
Address Explanation Setting QPIT
Settings
Factory
Settings
00H Password 0 54H -
01H 0FH -
02H Market 0:Word 1:Japan
2:Custom(MJ-)
∗∗
3:Custom(Stylus Color)
∗∗
4:Custom (other name)
∗∗
00H
(
∗
1)
03H 1st dot adjustment
-40≤ n ≤40 (by 1/1440 inch)
00H
(
∗
1)
04H Bi-D adjustment data
-36≤ n ≤36 (by 1/1440 inch)
00H
(
∗
1)
05H Uni-D adjustment
-36≤ n ≤36 (by 1/1440 inch)
00H
(
∗
1)
06H Reserved 00H -
07H Reserved 00H -
08H Carriage speed adjustment
data
-4≤ n ≤4 (by G.A timer unit)
00H
(
∗
1)
09H Reserved 00H -
0AH Head actuator rank ID for
VhN
12H
(
∗
1)
0BH Head actuator rank ID for
Twhs
01H
(
∗
1)
0CH Reserved 00H -
0DH Reserved 00H -
0EH Reserved 00H -
0FH Reserved 00H -
10H Password 1 5AH -
11H 0FH -
12H Custom EEPROM sub
number
00H 00H
13H 00H 00H
14H 00H 00H
15H 00H 00H
16H Reserved 00H -
17H Reserved 00H -
18H CPSI password 00H 00H
19H 00H 00H
1AH 00H 00H
1BH 00H 00H
1CH CPSI flags bit7:CPSI license
0:Disable
1:Enable
bit6:CPSI Font license
0:Disable
1:Enable
00H 00H
1DH Reserved 00H -
1EH Reserved 00H -
1FH EEPROM Revision 42H -
20H Password 2 5AH -
21H 0FH -
22H Interface selection 0:Auto 1:Parallel
2:Serial
00H
00H
∗
2
Note)
∗∗
change model name of IEEE1284 device ID.
∗
1 Adjusted at factory.
∗
2 Initialized after performed panel initialization of EEPROM.
