EPSON Stylus Color600 Service Manual
Rev.A
A-5
Address Explanation Setting QPIT
settings
Factory
settings
23H Interface wait time 0 to 255 (by second) 0AH 0AH
24H Parallel I/F speed 0:High speed 1:Normal 00H 00H
25H Reserved 00H -
26H Reserved 00H -
27H Print direction control 0:Bi-D 1:Uni-D 2:Auto 02H 02H
28H CG table 0:PC437 1:PC850 00H
(
∗
1)
29H Reserved 00H -
2AH Auto LF/Network I/F mode bit1:Network I/F mode (0=off, 1=on)
bit0:Auto line feed (0=off, 1=on)
00H 00H
2BH Panel mask function bit5:Extedned settings
bit2:Cleaning
bit1:Replace I/C
bit0:Load/Eject
00H 00H
2CH Reserved 00H -
2DH Reserved 00H -
2EH Reserved 00H -
2FH Reserved 00H -
30H Password 3 5AH -
31H 0FH -
32H Reserved 00H -
33H Reserved 00H -
34H Top margin 42 to 44X360 (by 1/360 inch) 78H 78H
35H 00H 00H
36H Reserved 00H -
37H Reserved 00H -
38H Reserved 00H -
39H Reserved 00H -
3AH Reserved 00H -
3BH Reserved 00H -
3CH Reserved 00H -
3DH Reserved 00H -
3EH CR-phase of Home 00H 00H
3FH ERROR Number 00H 00H
40H Password 4 5AH -
41H 0FH -
42H Ink flags bit7:resrved
bit6:black
“one time”
bit5:color
“one time”
bit4:Initial fill required
bit3:reserved
bit2:in cleaning seq.
bit1:black CL required
bit0:color CL required
00H 10H
43H Ink flags 2 bit2:YMC cartridge changed and
cleaned
0:first cartridge
1:changed
bit1:Black cartridge changed and
cleaned
0:first cartridge
1:changed
bit0:Black cartridge changed and
cleaned
0:with YMC cartridge
1:alone
00H 00H
To Next Page
