Epson EB-1776W User Manual

Notations Used in This Guide ........................ 2
Introduction
Projector Features .......................................... 8
List of Functions by Model........................................8
Quick and Easy Set up, Projection, and Storage ..........................8
Connecting with a USB cable and projecting (USB Display)................8
Easy Image Correction...........................................8
Adjusting the projected image to automatically fit into the screen frame - Screen
Fit - (EB-1776W only)..........................................8
Detecting projector movements and automatically correcting image distortion
.........................................................9
Useful Functions for Expanding the Scope of Your Presentations..............9
Project two images simultaneously (Split Screen) (EB-1776W/EB-1771W/
EB-1761W only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Increasing projection content in wide (WXGA) screen (EB-1776W/EB-1771W/
EB-1761W only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Connecting to a wireless LAN and projecting images from the computer's screen
(EB-1776W/EB-1771W/EB-1761W only) .............................10
Connecting a projector and a computer wirelessly with Quick Wireless Connection
(EB-1776W/EB-1771W/EB-1761W only) .............................10
Projecting images from portable devices over a network (EB-1776W/EB-1771W/
EB-1761W only) .............................................10
Connect a USB storage device and project PDFs, movies, and images (Slideshow)
........................................................10
Making the most of the remote control.............................10
Optimum color mode for projecting medical images...................10
Part Names and Functions .................................. 11
Front/Top...................................................11
Rear .......................................................12
Base......................................................13
Control Panel ................................................14
Remote Control ...............................................15
Replacing the remote control batteries ............................. 18
Remote control operating range.................................19
Preparing the Projector
Installing the Projector ..................................... 21
Installation Methods ........................................... 21
Installation methods ......................................... 21
Screen Size and Approximate Projection Distance.......................22
Connecting Equipment ..................................... 24
Connecting a Computer......................................... 24
Connecting Image Sources.......................................25
Connecting USB Devices.........................................26
Installing the Wireless LAN Unit ....................................27
Basic Usage
Projecting Images ......................................... 29
From Installation to Projection .....................................29
Automatically Detect Input Signals and Change the Projected Image (Source Search)
.......................................................... 30
Switching to the Target Image by Remote Control.......................31
Projecting with USB Display......................................31
System requirements......................................... 31
Connecting for the first time ....................................32
Uninstalling ...............................................33
Adjusting Projected Images ................................ 35
Automatically Adjust to Fit into the Screen Frame - Screen Fit - (EB-1776W only)
.......................................................... 35
Correcting Keystone Distortion ....................................37
Correcting automatically - Auto H/V-Keystone - (EB-1776W only) . . . . . . . . . . . 37
Correcting automatically - Auto V-Keystone - (EB-1771W/EB-1761W/EB-1751
only)....................................................38
Correcting manually - manual H/V-Keystone - ........................38
Correcting manually - Quick Corner -..............................39
Adjusting the Image Size ........................................41
Adjusting the Image Position .....................................41
Adjusting the Horizontal Tilt ......................................42
Contents
3

Epson EB-1776W Specifications

General

Native aspect ratio	16:10
Projection distance	1.35 - 1.62 m
Projection technology	3LCD
Contrast ratio (typical)	2000:1
Screen size compatibility	30 - 300 \
Projection distance (tele)	0.8 - 8.2 m
Projection distance (wide)	0.7 - 6.8 m
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	+-30 °
Keystone correction, horizontal	+-20 °
Focus	-
Throw ratio	1.04 - 1.26:1
Zoom capability	Yes
Focal length range	13.52 - 16.22 mm
Lamp type	UHE
Lamp power	230 W
Light source type	Lamp
Service life of light source	4000 h
Full HD	No
Video color modes	Cinema, Dynamic
USB connector type	USB Type-A, USB Type-B
USB 2.0 ports quantity	2
Noise level	40 dB
Country of origin	China
Noise level (economic mode)	30 dB
On Screen Display (OSD) languages	ARA, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HEB, HUN, ITA, NOR, POL, POR, RUM, RUS, SLK, SLV, SWE, TUR, UKR
RMS rated power	1 W
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Display diagonal	0.59 \
Power source	AC
Power consumption (standby)	0.4 W
Power consumption (typical)	304 W
Power consumption (PowerSave)	203 W
Cables included	AC, USB
Bundled software	EasyMP Monitor, EasyMP Network Projection, EasyMP Slide Converter
Pallet width	800 mm
Pallet height	2207 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	102 pc(s)
Quantity per pallet (UK)	136 pc(s)
Quantity per pallet layer	6 pc(s)
Quantity per pallet layer (UK)	8 pc(s)

Weight and Dimensions

Depth	210 mm
Width	292 mm
Height	44 mm
Weight	1710 g
Package depth	435 mm
Package width	284 mm
Package height	121 mm
Package weight	3660 g
