Epson EB-1776W User Manual

Configuration Menu Table
Settable items vary depending on the model being used and the image
signal and source being projected.
Top Menu Name Submenu Name Items or Setting Values
Image menu
s p.80
Color Mode Dynamic, Presentation, Theatre,
Photo, sRGB, Blackboard,
Whiteboard, Customized, and
DICOM SIM
Brightness -24 to 24
Contrast -24 to 24
Color Saturation -32 to 32
Tint -32 to 32
Sharpness -5 to 5
Abs. Color Temp. 5000K to 10000K
Color Adjustment R: -16 to 16
G: -16 to 16
B: -16 to 16
Auto Iris On and Off
Signal menu
s p.81
Auto Setup On and Off
Resolution Auto, Wide, and Normal
Tracking -
Sync. -
Position Up, Down, Left, and Right
Progressive Off, Video, and Film/Auto
Noise Reduction Off, NR1, and NR2
HDMI Video Range Auto, Normal, and Expanded
Input Signal Auto, RGB, and Component
Top Menu Name Submenu Name Items or Setting Values
Video Signal Auto, NTSC, NTSC4.43, PAL,
M-PAL, N-PAL, PAL60, and
SECAM
Aspect Normal, 4:3, 16:9, Full, Zoom,
and Native
Overscan Auto, Off, 4%, and 8%
Image processing Fast, Fine
Settings menu
s p.82
Keystone H/V-Keystone and Quick Corner
Split Screen -
Control Panel Lock Full Lock, Partial Lock, and Off
Pointer Shape Pointer 1, 2, and 3
Power Consumption Normal and ECO
Volume 0 to 20
Remote Receiver Front/Rear, Front, Rear, and Off
User Button Power Consumption, Info,
Progressive, Test Pattern, Multi-
screen, and Resolution
Test Pattern -
Extended menu
s p.84
Display Messages, Display Background,
Startup Screen, and A/V Mute
User's Logo -
Projection Front, Front/Ceiling, Rear, and
Rear/Ceiling
Operation Direct Power On, Sleep Mode,
Sleep Mode Timer, Lens Cover
Timer, and High Altitude Mode
Standby Mode Communication On and
Communication Off
USB Type B USB Display and Link 21L
List of Functions
77

Epson EB-1776W Specifications

General

Native aspect ratio	16:10
Projection distance	1.35 - 1.62 m
Projection technology	3LCD
Contrast ratio (typical)	2000:1
Screen size compatibility	30 - 300 \
Projection distance (tele)	0.8 - 8.2 m
Projection distance (wide)	0.7 - 6.8 m
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	+-30 °
Keystone correction, horizontal	+-20 °
Focus	-
Throw ratio	1.04 - 1.26:1
Zoom capability	Yes
Focal length range	13.52 - 16.22 mm
Lamp type	UHE
Lamp power	230 W
Light source type	Lamp
Service life of light source	4000 h
Full HD	No
Video color modes	Cinema, Dynamic
USB connector type	USB Type-A, USB Type-B
USB 2.0 ports quantity	2
Noise level	40 dB
Country of origin	China
Noise level (economic mode)	30 dB
On Screen Display (OSD) languages	ARA, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HEB, HUN, ITA, NOR, POL, POR, RUM, RUS, SLK, SLV, SWE, TUR, UKR
RMS rated power	1 W
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Display diagonal	0.59 \
Power source	AC
Power consumption (standby)	0.4 W
Power consumption (typical)	304 W
Power consumption (PowerSave)	203 W
Cables included	AC, USB
Bundled software	EasyMP Monitor, EasyMP Network Projection, EasyMP Slide Converter
Pallet width	800 mm
Pallet height	2207 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	102 pc(s)
Quantity per pallet (UK)	136 pc(s)
Quantity per pallet layer	6 pc(s)
Quantity per pallet layer (UK)	8 pc(s)

Weight and Dimensions

Depth	210 mm
Width	292 mm
Height	44 mm
Weight	1710 g
Package depth	435 mm
Package width	284 mm
Package height	121 mm
Package weight	3660 g
